Jupiter’s Demise, Continued
9-01: Missile shell rolls out of RIM area to the field for cutting with Primacord. (Bob Young, Dev Date: Spring 1963)
9-02: Stripped missile shell is rolled off the wagon to begin the Primacord destruction process. (Bob Young, Dev Date: Spring 1963)
Parts Of Missile Shell After Primacord Cutting Parts Of Missile Shell After Primacord Cutting
9-05: Parts of the missile shell after being cut by Primacord explosive rope. (Bob Young, Dev Date: Spring 1963)
9-04: What happens when Primacord explosion goes bad. Bottom of the missile's LOX tank. (Bob Young, Spring 1963)
9-06: Sections of missile shell after the Primacord explosion cuts it into short pieces. (Bob Young, Dev Date: Spring 1963)
9-07: More parts of the missile shell after being cut by Primacord explosive rope. This was near the end of the destruction process. (Bob Young, Dev Date: Spring 1963)
Near The End Of Missile Destruction Process Near The End Of Missile Destruction Process
9-08: Placing the Primacord, Calhoun & Anderson. (Jim Calhoun, Dev Date: Spring 1963)
Primacord Explosion Aftermath; Jim Calhound & Anderson Primacord Explosion Aftermath; Jim Calhound & Anderson
9-09: The aftermath of setting of the Primacord, Jim Calhoun & Anderson. (Jim Calhoun, Dev Date: Spring 1963)
Missile's Bottom After Being Severed with Primacord Missile's Bottom After Being Severed with Primacord
9-03: This photo shows the bottom of the missile after having been severed with Primacord. Note the "roll control" nozzle on the bottom right of missile shell. The Rocketdyne engines were all removed and shipped back to the U.S.A. (Bob Young, Dev Date: Spring 1963)
Calhoun & Anderson Placing Primacord Calhoun & Anderson Placing Primacord
Page 8 Page 8 Stripped Missile Shell Rolled Off The Wagon For Primacord Cutting Stripped Missile Shell Rolled Off The Wagon For Primacord Cutting
Engine Removed, Missile Shell Rolls Out Of RIM For Primacord Cutting Engine Removed, Missile Shell Rolls Out Of RIM For Primacord Cutting
Primacord Explosion Goes Bad; Bottom Of LOX Tank Primacord Explosion Goes Bad; Bottom Of LOX Tank
Sections Of Missile Shell After Primacord Cutting Sections Of Missile Shell After Primacord Cutting
Page 10 Page 10
